Honeywell MC-TAIH02 51304453-150 FTA, HLAI/STI, Comp Term,CC NEW IN BOX
Lead time:3-5 days
New with one year warranty
DESCRIPTION
The Combo Interface Module, CIM, enables a TPS xPM STI-MV IOP module to accept any mix of analog 4-20ma or bidirectional DE inputs from field instruments on a per channel basis. The CIM accepts 4byte DE, 6 byte DE (single or multivariable), analog 4-20ma(1-5volts) on any of the 16 input channels. The CIM is installed between the FTA IOP connector and the IOP cable. In redundant applications, two CIMs are required. The Combo Interface Module is ideal for both MRO and new installations, eliminating the need for two IOP module types (analog & DE), enabling digital integration and higher channel densities while utilizing less card slots and FTAs.
FEATURES • Accepts Analog or Bi-Directional DE on Any Channel • Compatible With Any STI-MV and Most FTAs • Simple to Install & Configure • Analog-to-DE Transmitter Mode Change from TPS • No Wiring or Software Changes
OPERATION The CIM always presents 16 channels of DE data to the STI-MV IOP module, either directly from a DE field instrument or internally generated from the CIM’s internal A/D converter. The CIM operates by allowing all DE communication traffic to pass directly through the CIM, or converting analog 4-20ma signals to 4byte DE digital and then passing that digital signal to the STI-MV IOP module.
COMPATIBILITY The CIM module is release independent and does NOT require any system modification. It is fully compatible with all single and multivariable field instruments. All digital bi-directional DE channel data is unchanged by the CIM. Analog inputs are processed with minimal delay and broadcasted at the 4byte DE data rate to the STI-MV IOP. On DE channels, there is no impact or disturbances as a result of communicator usage. On analog channels, there is no impact or disturbances as a result of HART communicator usage. Channels configured for DE may be connected to a Smartline transmitter in analog mode and later switched to DE mode from the TPS console. Channels configured for analog may be connected to a Smartline transmitter in analog mode and can NOT be inadvertently switched to DE mode from the TPS console. The CIM may be used with any STI-MV IOP module and a variety of FTA types (see TABLE 1: Compatible FTAs & IOPs).
